September 23–25, 2016
Located on Constitution Avenue, adjacent to the National Museum of American History and the Washington Monument, the National Museum of African American History and Culture (NMAAHC) will house exhibit galleries, administrative spaces, theatre space and collections storage space. As lead designer for the Freelon Adjaye Bond/SmithGroup (FAB) team, David Adjaye’s approach has been to establish both a meaningful relationship to this unique site as well as a strong conceptual resonance with America’s deep and longstanding African heritage. The design rests on three cornerstones: the “corona” shape and form of the building; the extension of the building out into the landscape—the porch; and the bronze filigree envelope.
Situated on the Washington Monument grounds the museum maintains a subtle profile in the landscape—more than half is below ground—with five storeys above. The corona is based on elements of the Washington Monument, closely matching the 17-degree angle of the capstone and the panel size and pattern has been developed using the Monument stones as a reference. The entire building is wrapped in an ornamental bronze lattice that is a historical reference to African American craftsmanship. The density of the pattern can be modulated to control the amount of sunlight and transparency into the interior. The south entry is composed of the porch and a central water feature. An extension of the building out into the landscape, the porch creates an outdoor room that bridges the gap between the interior and exterior.
At 50m (49 feet, 2 inches) deep, the setback is similar to other buildings on the north side of the Mall. The underside of the porch roof is tilted upward allowing reflection of the moving water below. This covered area creates a microclimate where breezes combine with the cooling waters to generate a place of refuge from the hot summer sun. There is also an outdoor patio on the porch rooftop that is accessed from a mezzanine level within the building.
Inside the building, visitors will be guided on a historical and emotional journey, characterised by vast, column free spaces, a dramatic infusion of natural light and a diverse material palette comprising pre-cast concrete, timber and a glazed skin that sits within the bronze lattice. Below ground, the ambience is contemplative and monumental, achieved by the triple height history gallery and symbolised by the memorial space—the “oculus”—that brings light diffused by a cascade of water into the contemplative space from the Monument grounds. Moving upwards, the views become pivotal, as one circulates along the corona with unrivalled panoramas of the Mall, Federal Triangle buildings and Monument Grounds.
Architect
Freelon Adjaye Bond/SmithGroup
Client
Smithsonian Institution
Structural Engineer
Guy Nordeson and Associates
Robert Silman Associates
Mechanical Engineer
WSP Flack + Kurtz
Sustainability Consultant
Rocky Mountain Institute
Total Area
420,000 ft2
Contract Value
540m USD
Landscape Architect
Gustafson Guthrie Nichol
Lighting Consultants
Fisher Marantz Stone
Acoustics / AV / Theatre / Multi-Media Consultants
Shen Milson Wilke
Façade Consultant
R.A. Heintges & Associates
Security Consultants
ARUP North America
